DELL-SD25TB5 Dell Pro SD25TB5 Docking Station

Dell Pro SD25TB5 Docking Station

• General Information

  ---

  Manufacturer: Dell Technologies
  Manufacturer Part Number: DELL-SD25TB5
  Manufacturer Website Address: http://www.delltechnologies.com
  Brand Name: Dell
  Product Series: Pro
  Product Model: SD25TB5
  Product Name: Pro SD25TB5 Docking Station
  Product Type: Docking Station

  Technical Information

  ---

  Connectivity Technology: Wired
  Supported Resolutions:
• 7680 x 4320
• 6144 x 3456
• 5120 x 2160
• 3840 x 2160
• 3440 x 1440
• 2560 x 1440
Screen Mode Supported:
• 4K @ 120Hz
• 8K @ 60Hz
• 6K @ 60Hz
• 5K @ 60Hz
• WQHD @ 60Hz
• QHD @ 60Hz
Management Features:
• Dell Command Update (DCU)
• Intel AMT over Thunderbolt with select Intel vPro PCs
• Kernel Direct Memory Access (DMA) Protection
• Wake-on-LAN
• Dock Power Button Sync
• PXE Boot
• MAC Address Pass-through
• Port Disablement
• WLAN to LAN Switch
Device Supported: Notebook

Network & Communication

---

Ethernet Technology: 2.5 Gigabit Ethernet

Interfaces/Ports

---

Host Interface: Thunderbolt 5
Total Number of USB Ports: 6
Number of USB 3.2 Gen 2 Type-A Ports: 4
Number of USB Type-C Ports: 2
USB Type-C: Yes
USB Type-C Detail: 1 x USB-C 3.2 Gen 2 Multi-function DisplayPort 2.1, 1 x USB-C 3.2 Gen 2 (10 Gbps)
Number of USB Type-A Ports: 4
USB Type-A: Yes
Network (RJ-45): Yes
Number of DisplayPorts: 2
DisplayPort: Yes
DisplayPort Version: 2.1
Number of HDMI Ports: 1
HDMI: Yes
Thunderbolt: Yes
Thunderbolt Ports Quantity: 2

Software

---

Operating System Supported:

ChromeOS 141

Red Hat Enterprise Linux 9.7

macOS

Ubuntu 24.04

Windows 11

Windows 10

Power Description

---

Maximum Power Supply Wattage: 330 W

Physical Characteristics

---

Height: 8.07"
Width: 3.54"
Depth: 1.39"
Weight (Approximate): 1.39 lb

Miscellaneous

---

Kensington Security Slot: Yes
