Cisco Meraki offers a broad range of switches that are designed to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches. Meraki access and aggregation switches are all managed through an elegant, intuitive cloud interface, freeing administrators to spend less time on configuration and more time on meeting business needs. The Meraki dashboard makes getting your switches up and running simple. The intuitive user interface removes repetitive, time-consuming processes, while advanced features like Cloud CLI enable administrators to retain advanced control. A powerful centralized management interface gives administrators deep visibility into the network and how it is used. See which switches are near capacity across hundreds of sites. Quickly provision and reconfigure switch ports with security, quality of service (QoS), and more. The Meraki dashboard provides unified policies, event logs, and monitoring, making switch management efficient and scalable. Product highlights - Meraki switches include all of the traditional Ethernet features found on the highest-end products, including:
- Wide range of models for campus, branch and rugged environments, from basic Layer 2 to high-performance Layer 3
- Up to 10 GbE access ports and 100 GbE uplinks for scalable deployments
- True zero-touch configuration that scales with organizational needs
- Integrated troubleshooting, logging, and alerting to lower operational costs
- Energy-efficient, low-noise design with fanless options
- Cloud management for reduced cost, overhead, and faster issue resolution
- Advanced security with IEEE 802.1x, MAC-based RADIUS authentication, and multiple admin roles
- QoS to prioritize critical traffic like voice and video
- Link Aggregation (LACP) and Rapid Spanning Tree Protocol (RSTP) for high availability and network stability
- Voice VLAN, DHCP snooping, and IGMP snooping to optimize and secure network traffic
- StackPower, advanced physical stacking, multigigabit, and UPOE+ options on select models
Introducing the Catalyst 9200L-M | Day 0 native cloud management with Catalyst 9200L-M The Catalyst 9200L-M is a fixed, stackable access switch designed to simplify deployment and management and serve as an ideal choice for customers transitioning from Meraki MS switches or for advanced branch environments where ease of use, reliability, flexibility, and cloud scale are critical. - 24/48 port options, 4x 10GbE, 4x 10GbE and 2× 25 GbE uplinks, 30W PoE+, and up to 10GbE RJ45 ports.
-
General Information
Manufacturer: Cisco Systems, Inc Manufacturer Part Number: C9200L-48P-4G-M Manufacturer Website Address: http://www.cisco.com Brand Name: Cisco Meraki Product Line: Catalyst Product Series: 9200 Product Model: C9200L-48P-4G-M Product Name: Catalyst C9200L-48P-4G-M Ethernet Switch Marketing Information: Cisco Meraki offers a broad range of switches that are designed to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches. Meraki access and aggregation switches are all managed through an elegant, intuitive cloud interface, freeing administrators to spend less time on configuration and more time on meeting business needs. The Meraki dashboard makes getting your switches up and running simple. The intuitive user interface removes repetitive, time-consuming processes, while advanced features like Cloud CLI enable administrators to retain advanced control. A powerful centralized management interface gives administrators deep visibility into the network and how it is used. See which switches are near capacity across hundreds of sites. Quickly provision and reconfigure switch ports with security, quality of service (QoS), and more. The Meraki dashboard provides unified policies, event logs, and monitoring, making switch management efficient and scalable. Product highlights - Meraki switches include all of the traditional Ethernet features found on the highest-end products, including:
- Wide range of models for campus, branch and rugged environments, from basic Layer 2 to high-performance Layer 3
- Up to 10 GbE access ports and 100 GbE uplinks for scalable deployments
- True zero-touch configuration that scales with organizational needs
- Integrated troubleshooting, logging, and alerting to lower operational costs
- Energy-efficient, low-noise design with fanless options
- Cloud management for reduced cost, overhead, and faster issue resolution
- Advanced security with IEEE 802.1x, MAC-based RADIUS authentication, and multiple admin roles
- QoS to prioritize critical traffic like voice and video
- Link Aggregation (LACP) and Rapid Spanning Tree Protocol (RSTP) for high availability and network stability
- Voice VLAN, DHCP snooping, and IGMP snooping to optimize and secure network traffic
- StackPower, advanced physical stacking, multigigabit, and UPOE+ options on select models
Introducing the Catalyst 9200L-M | Day 0 native cloud management with Catalyst 9200L-M The Catalyst 9200L-M is a fixed, stackable access switch designed to simplify deployment and management and serve as an ideal choice for customers transitioning from Meraki MS switches or for advanced branch environments where ease of use, reliability, flexibility, and cloud scale are critical. - 24/48 port options, 4x 10GbE, 4x 10GbE and 2× 25 GbE uplinks, 30W PoE+, and up to 10GbE RJ45 ports.
Product Type: Ethernet Switch Technical Information
Features: - Zero-Touch Provisioning (ZTP)
- DHCP Relay
- DHCP Snooping
- Access Control List
- Hot-swappable
- Dynamic ARP Inspection
- Broadcast Storm Control
Interfaces/Ports
Total Number of Network Ports: 48
Network (RJ-45): Yes
Uplink Port: Yes
Stack Port: Yes
Port/Expansion Slot Details: - 48 x Gigabit Ethernet PoE+
- 4 x Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported: Twisted Pair
Ethernet Technology: Gigabit Ethernet
Network Technology: - 1000Base-T
- 1000Base-X
Maximum Data Transfer Rate: 128 MB/s
I/O Expansions
Total Number of Expansion Slots: 4
Expansion Slot Type: SFP
Number of SFP Slots: 4
Network & Communication
Layer Supported: 3
Networking Standards: - IEEE 802.3at
- IEEE 802.1p
- IEEE 802.1Q
- IEEE 802.1s
- IEEE 802.1ab
- IEEE 802.3ad
- IEEE 802.1x
Management & Protocols
Manageable: Yes
Power Description
PoE (RJ-45) Port: Yes
PoE Budget: 1440 W
Power Source: - Power Supply
- AC
Redundant Power Supply Supported: Yes
Physical Characteristics
Compatible Rack Unit: 1U
Form Factor: Rack-mountable
Height: 1.7"
Width: 17.5"
Depth: 12.9"
Weight (Approximate): 10.58 lb
Miscellaneous
Package Contents: - Catalyst C9200L-48P-4G-M Ethernet Switch
- 1 x Power Supply
- 3 x System Fans
- Rack-Mount Brackets
Environmental Compliance: Restriction of Hazardous Substances (RoHS) 5 Warranty
Limited Warranty: Lifetime
 Dedicated account managers are available to assist you with purchasing and presales questions at 877-712-2230 Monday through Friday 8-5pm. What Forms Of Payment Do We Take?We accept all forms of payment including Visa, Mastercard, American Express, Discover, Wire Transfer, and Check in Advance. Purchase orders are accepted and net terms are given based on a credit check. Why Buy From ITO?ITO Solutions, Inc. purpose is to provide you, our client, with best in class technology solutions to help you run your network efficiently by leveraging our integrity, partnerships, and years of experience within the IT industry. Our account managers are here to answer your questions and provide you with solutions very effectively.
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Key Features
Product Description
Cisco Meraki offers a broad range of switches that are designed to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches. Meraki access and aggregation switches are all managed through an elegant, intuitive cloud interface, freeing administrators to spend less time on configuration and more time on meeting business needs. The Meraki dashboard makes getting your switches up and running simple. The intuitive user interface removes repetitive, time-consuming processes, while advanced features like Cloud CLI enable administrators to retain advanced control. A powerful centralized management interface gives administrators deep visibility into the network and how it is used. See which switches are near capacity across hundreds of sites. Quickly provision and reconfigure switch ports with security, quality of service (QoS), and more. The Meraki dashboard provides unified policies, event logs, and monitoring, making switch management efficient and scalable. Product highlights - Meraki switches include all of the traditional Ethernet features found on the highest-end products, including:
- Wide range of models for campus, branch and rugged environments, from basic Layer 2 to high-performance Layer 3
- Up to 10 GbE access ports and 100 GbE uplinks for scalable deployments
- True zero-touch configuration that scales with organizational needs
- Integrated troubleshooting, logging, and alerting to lower operational costs
- Energy-efficient, low-noise design with fanless options
- Cloud management for reduced cost, overhead, and faster issue resolution
- Advanced security with IEEE 802.1x, MAC-based RADIUS authentication, and multiple admin roles
- QoS to prioritize critical traffic like voice and video
- Link Aggregation (LACP) and Rapid Spanning Tree Protocol (RSTP) for high availability and network stability
- Voice VLAN, DHCP snooping, and IGMP snooping to optimize and secure network traffic
- StackPower, advanced physical stacking, multigigabit, and UPOE+ options on select models
Introducing the Catalyst 9200L-M | Day 0 native cloud management with Catalyst 9200L-M The Catalyst 9200L-M is a fixed, stackable access switch designed to simplify deployment and management and serve as an ideal choice for customers transitioning from Meraki MS switches or for advanced branch environments where ease of use, reliability, flexibility, and cloud scale are critical. - 24/48 port options, 4x 10GbE, 4x 10GbE and 2× 25 GbE uplinks, 30W PoE+, and up to 10GbE RJ45 ports.
- Features: Zero-Touch Provisioning (ZTP), DHCP Relay, DHCP Snooping, Access Control List, Hot-swappable, Dynamic ARP Inspection, Broadcast Storm Control
- Total Number of Network Ports: 48
- Network (RJ-45): Yes
- Uplink Port: Yes
- Stack Port: Yes
- Port/Expansion Slot Details: 48 x Gigabit Ethernet PoE+, 4 x Gigabit Ethernet Expansion Slot
- Media Type Supported: Twisted Pair
- Ethernet Technology: Gigabit Ethernet
- Network Technology: 1000Base-T, 1000Base-X
- Maximum Data Transfer Rate: 128 MB/s
- Total Number of Expansion Slots: 4
- Expansion Slot Type: SFP
- Number of SFP Slots: 4
- Layer Supported: 3
- Networking Standards: IEEE 802.3at, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.1x
- Manageable: Yes
- PoE (RJ-45) Port: Yes
- PoE Budget: 1440 W
- Power Source: Power Supply, AC
- Redundant Power Supply Supported: Yes
- Compatible Rack Unit: 1U
- Form Factor: Rack-mountable
- Height: 1.7"
- Width: 17.5"
- Depth: 12.9"
- Weight (Approximate): 10.58 lb
- Package Contents:
Catalyst C9200L-48P-4G-M Ethernet Switch,1 x Power Supply,3 x System Fans,Rack-Mount Brackets, - Environmental Compliance: Restriction of Hazardous Substances (RoHS) 5
- Limited Warranty: Lifetime
|
|
|
|
|
|
|
